The BMW X5 xDrive45e measures 194.3 inches (4,922 mm) in length[1]. This measurement applies to pre-facelift models (2019-2023), while post-LCI facelift versions extend slightly to 4,935 mm due to redesigned bumpers[2]. The plug-in hybrid shares identical exterior dimensions with standard gasoline X5 variants despite housing the PHEV battery system underneath[3].
Full Exterior Dimensions
Length, Width, and Height
| Dimension | Measurement (inches) | Measurement (mm) |
|---|---|---|
| Length | 194.3[1] | 4,922[4] |
| Width (without mirrors) | 78.9[1] | 2,004[4] |
| Width (with mirrors) | 87.3[1] | 2,218[4] |
| Height | 68.7[1] | 1,745[4] |
| Wheelbase | 117.1[1] | 2,975[5] |
| Ground Clearance | 8.4[2] | 212[2] |
Note: LCI facelift models (2024+) are 13mm longer than pre-LCI versions due to bumper redesigns.
Pre-LCI vs LCI Facelift Dimensions
| Model | Generation | Length (mm) | Length (inches) |
|---|---|---|---|
| xDrive45e | Pre-LCI (2019-2023) | 4,922[4] | 193.8 |
| xDrive50e | LCI (2024+) | 4,935[2] | 194.3 |
The 13mm length increase in facelift models comes entirely from redesigned bumpers rather than structural changes to the body[2]. The xDrive50e replaces the xDrive45e designation in the updated lineup.
Interior and Cargo Specifications
Passenger Space
| Dimension | Front | Rear |
|---|---|---|
| Headroom | 40.8 in[6] | — |
| Legroom | 39.8 in[6] | 37.4 in[6] |
| Shoulder Room | 60.0 in[6] | 58.1 in[6] |
| Seating Capacity | 5 passengers[4] | — |
Cargo Volume
The X5 xDrive45e sacrifices some cargo space compared to gasoline variants due to the underfloor battery pack:
- Rear seats upright: 33.1 cu ft[1] (500 liters)[4]
- Standard X5 comparison: 33.9 cu ft seats up / 72.3 cu ft seats folded[6]
The PHEV battery placement reduces cargo capacity compared to non-hybrid X5 models. For buyers prioritizing cargo space, the standard X5 xDrive40i offers more flexibility.
To understand whether the BMW X5 offers third-row seating, note that the xDrive45e is only available in 5-seat configuration.
How X5 xDrive45e Compares to Competitors
| Vehicle | Length (in) | Width (in) | Height (in) | Wheelbase (in) |
|---|---|---|---|---|
| BMW X5 xDrive45e | 194.3[1] | 78.9[1] | 68.7[1] | 117.1[1] |
| Mercedes-Benz GLE 450e | 193.8 | 76.4 | 69.5 | 117.9 |
| Volvo XC90 Recharge | 194.8 | 79.1 | 69.3 | 117.5 |
| Porsche Cayenne E-Hybrid | 193.9 | 78.1 | 66.0 | 114.0 |
The X5 xDrive45e positions itself mid-pack among luxury PHEV SUVs, with competitive length and width while maintaining a practical height for most garages. For a detailed comparison with smaller BMW SUVs, see our guide on BMW X3 vs X5 differences.
Powertrain Specifications
xDrive45e System
| Specification | Value |
|---|---|
| Engine | 3.0L Turbocharged Inline-6[4] |
| Engine Power | 282 hp @ 5,000 rpm[4] |
| Engine Torque | 331 lb-ft @ 1,500 rpm[4] |
| Electric Motor | 111 hp (83 kW)[4] |
| Combined System Power | 394 hp[5] |
| Combined System Torque | 443 lb-ft[4] |
| Battery Capacity | 21.6 kWh[4] |
| Electric Range (WLTP) | 54 miles (87 km)[4] |
| 0-62 mph | 5.6 seconds[5] |
| Top Speed | 146 mph[5] |
| Transmission | 8-speed automatic[4] |
| Drivetrain | xDrive AWD[4] |
Practical Garage Fit Considerations
Standard Garage Compatibility
| Garage Type | Typical Dimensions | X5 xDrive45e Fit |
|---|---|---|
| Single-car garage | 12′ x 22′ (144″ x 264″) | Tight fit with limited door clearance |
| Two-car garage | 20′ x 20′ (240″ x 240″) | Comfortable fit |
| Three-car garage | 32′ x 22′ (384″ x 264″) | Ample space |
At 194.3 inches long and 78.9 inches wide (87.3 inches with mirrors), the X5 xDrive45e fits comfortably in most two-car garages[1]. Single-car garages may present challenges for door opening clearance.
Tips for Measuring Your Space
- Allow at least 24-36 inches in front and behind the vehicle for comfortable access
- Consider the 87.3-inch mirror-to-mirror width when measuring garage door clearance[1]
- The 68.7-inch height fits standard 7-foot garage door openings with clearance[1]
Key Takeaways
- BMW X5 xDrive45e length: 194.3 inches (4,922mm pre-LCI / 4,935mm LCI)
- Width: 78.9 inches without mirrors, 87.3 inches with mirrors
- Height: 68.7 inches, fitting most standard garage openings
- Exterior dimensions match gasoline X5 models—only cargo space is slightly reduced due to battery placement
- Wheelbase of 117.1 inches provides stable handling and spacious rear legroom
Frequently Asked Questions
Is the BMW X5 xDrive45e the same size as the regular X5?
Yes, the X5 xDrive45e shares identical exterior dimensions with gasoline X5 variants within the same generation[4]. The plug-in hybrid system is integrated without affecting the body dimensions. The only difference is reduced cargo capacity (approximately 0.8 cu ft less) due to the underfloor battery placement[1][6].
What is the difference between xDrive45e and xDrive50e dimensions?
When comparing models from the same generation, the dimensions are identical. The xDrive50e (2024+) replaces the xDrive45e and measures 4,935mm (194.3 inches) in length[2]. The pre-LCI xDrive45e (2019-2023) measures 4,922mm, with the 13mm difference attributed to bumper redesigns rather than the powertrain[4].
Will the BMW X5 xDrive45e fit in my garage?
With a length of 194.3 inches, width of 78.9 inches (87.3 with mirrors), and height of 68.7 inches, the X5 xDrive45e fits most standard two-car garages comfortably[1]. For single-car garages (typically 12′ x 22′), clearance may be tight. Measure your garage and allow at least 24-36 inches in front and behind the vehicle for comfortable access.
How does X5 xDrive45e cargo space compare to the standard X5?
